socket Weld 90°elbow ,Threaded 90°elbow pipe fitting


90 DEG Threaded Pipe Elbow



ClASS



DimeNSioNS

SiZeS (iNCHeS)

1/8

1/4

3/8

1/2

3/4

1

1 1/4

1 1/2

2

2 1/2

3

4



2000

a



7/8

31/32

1 1/8

1 5/16

1 1/2

1 3/4

2

2 3/8

3

3 3/8

4 3/16

B



29/32

1 1/16

1 5/16

1 9/16

1 27/32

2 7/32

2 1/2

3 1/32

3 5/8

4 5/16

5 3/4

Weight



0.23

0.29

0.48

0.75

1.08

1.59

2.19

3.52

7.09

11.33

25.08



3000

a

7/8

31/32

1 1/8

1 5/16

1 1/2

1 3/4

2

2 3/8

2 1/2

3 1/4

3 3/4

4 1/2

B

29/32

1 1/16

1 5/16

1 9/16

1 27/32

2 7/32

2 1/2

3 1/32

3 11/32

4

4 3/4

6

Weight

0.27

0.35

0.58

0.97

1.42

2.29

2.77

5.43

5.87

11.03

17.50

33.20



6000

a

31/32

1 1/8

1 5/16

1 1/2

1 3/4

2

2 3/8

2 1/2

3 1/4

3 3/4

4 3/16

4 1/2

B

1 1/16

1 5/16

1 9/16

1 27/32

2 7/32

2 1/2

3 1/32

3 11/32

4

4 3/4

5 3/4

6

Weight

0.37

0.65

1.05

1.64

2.69

3.62

6.13

7.84

14.40

22.95

37.12

33.42

　

socket Weld 90°elbow ,Threaded 90°elbow pipe fitting

90 DEG Socket Weld Pipe Elbow



ClASS



DimeNSioNS

SiZeS (iNCHeS)

1/8

1/4

3/8

1/2

3/4

1

1 1/4

1 1/2

2

2 1/2

3

4





3000

a

7/8

7/8

31/32

1 1/8

1 5/16

1 1/2

1 3/4

2

2 3/8

3

3 3/8

4 3/16

B

29/32

29/32

1 1/16

1 5/16

1 9/16

1 27/32

2 7/32

2 1/2

3 1/32

3 11/16

4 3/8

5 3/4

C

0.420

0.555

0.690

0.855

1.065

1.330

1.675

1.915

2.406

2.906

3.535

4.545

D Min.

3/8

3/8

3/8

3/8

1/2

1/2

1/2

1/2

5/8

5/8

5/8

3/4

e

7/16

7/16

17/32

5/8

3/4

7/8

1 1/16

1 1/4

1 1/2

1 5/8

2 1/4

2 5/8

Weight

0.25

0.21

0.26

0.45

0.75

1.05

1.52

2.08

3.37

6.67

11.08

22.59

90 DEG Socket Weld Pipe Elbow

Note:    1. All Dimensions are in inches

2. Weights based on carbon steel (A105)

We are one of the eminent suppliers, complete sale suppliers and exporters of socket weld and screwed fittings like socket welding carbon steel pipe fittings, forged threaded carbon steel pipe fittings and steel pipe threaded fittings. Created from premium high-quality material these fittings are offered in innumerable shapes which include pipe elbow, pipe cross, steel pipe coupling, half coupling, pipe cap, piep tee etc. Giving smooth flow of liquid, our socket weld and screwed pipe fittings are known all over the world for their durability, higher functionality & reasonable price.
